Trydan 7.3kW Charger Pack + Shelly EM | Dynamic Charging with Solar Surplus

Trydan 7.3kW Charger + Shelly EM Pack — Smart EV charging for your home

This pack combines the V2C Trydan single-phase 7.3 kW charger with the Shelly EM and 2 50A current clamps. The most complete solution to charge your electric vehicle intelligently, safely and taking full advantage of your solar PV installation.

Benefits of EV Pack 2

• Smart dynamic charging: the Shelly EM measures total home consumption in real-time and automatically adjusts the Trydan power to never exceed your contracted limit. No outages, no upgrades.
• Use your solar energy: charge the car using the surplus from your PV panels, maximizing self-consumption and reducing your bill.
• Mobile control: free V2C Cloud and Shelly apps. Schedule charging during off-peak hours and view detailed statistics.
• Home automation: compatible with Home Assistant, Alexa, Google Home and MQTT.

What's included?

• V2C Trydan single-phase 7.3 kW charger, made in Spain, with 5-meter Type 2 cable and front LCD display
• Shelly EM single-phase WiFi energy meter
• 2 Shelly Split Core 50A current transformers

Technical specifications

• Power: 7.3 kW single-phase (32A · 230V)
• Configurable current: 6 to 32 A
• Connector: Type 2 (compatible with all European EVs)
• Cable: 5 meters
• Protection: IP54 / IK10
• Connectivity: WiFi, Bluetooth, OCPP 1.6 JSON
• PV compatibility: GoodWe, Fronius, Huawei, Ingeteam, Kostal, SMA, SolarEdge, SolaX, Victron + Shelly meters

⚠️ Important: Electrical protections are not included in this pack. If needed, check EV Pack 4 which includes them.

Fast shipping from Spain. Official V2C and Shelly warranty. Technical support in English.

Looking for a different setup? Compare our EV charger packs

• EV Pack 1 basic: Trydan 7.3 kW without cable + Shelly EM — budget option if you already have your own panel.
• EV Pack 4 with protections: Trydan 7.4 kW + ITC-BT-52 protections + Shelly EM — turnkey installation.
• EV Pack 3 three-phase: Trydan 22 kW + Shelly 3EM 120A — fast charging in three-phase installations.
• EV Pack 6 Trydan PRO: Trydan PRO with 4G, RFID, NFC, Ethernet + Shelly EM — for fleets and communities.
